TEMH 6000 - Broadband TEM Horn Antenna

NEW

  • TEMH 6000



Linear polarized Broadband TEM Horn Antenna (Aluminium) for receive and transmit applications, especially for generating radiated fields in close proximity immunity tests and UWB (ultra wideband) measurements. A typical application is the IEC 61000-4-39 standard.





Nominal Frequency Range: 380 MHz - 6 GHz
Usable Frequency Range: 300 MHz - 8 GHz
Polarisation: linear
Pattern Type: directional
Material: Aluminium
Max Power: 300 W
Connector: N - female
Impedance: 50 Ω nominal
Length: 300 (500) mm
Width: 260 mm
Height: 210 mm
Weight: 1.4 kg
Mounting: 22 mm Tube
Optional Accessories: Spacer 100
